Off-Grid Solar Systems

Off-grid solar systems are designed to operate independently of the utility grid, providing reliable power in remote areas or where grid access is limited. These systems are ideal for residential, industrial, and infrastructure projects requiring uninterrupted energy.

Key Components and Specifications

1. Solar Panels:

• o High-efficiency mono-crystalline or poly-crystalline panels.
• o Power output range: 250W to 550W.
• o Durable with an IP67-rated aluminum frame for long-lasting performance.

2. Inverters:

• o Pure sine wave inverters with high conversion efficiency (98%+).
• o Capacity: 1kVA to 50kVA, supporting single-phase and three-phase configurations.
• o Smart monitoring via integrated communication protocols (Wi-Fi, RS485).

3. Lithium-Ion Batteries:

• o Manufactured by S.P. Automation, these batteries deliver superior energy storage solutions.
• o Available capacities: 2kWh to 50kWh.
Features:
• • High energy density.
• • Long lifecycle: 5000+ cycles.
• • Built-in Battery Management System (BMS) for enhanced safety.

4. Solar Charge Controllers:

• o Maximum Power Point Tracking (MPPT) and Pulse Width Modulation (PWM) options.
• o Voltage support: 12V, 24V, 48V systems.
• o Efficiency: 99%+.

5. Surge Protection Devices (SPDs):

• o Protects sensitive solar system components from power surges.
• o Complies with international standards for lightning and surge protection.

6. Mounting Structures:

• o Durable, corrosion-resistant structures designed for ground and rooftop installations.

Applications

• • Remote villages and agricultural setups.
• • Industrial units in off-grid locations.
• • Residential homes requiring energy independence.

On-Grid Solar Systems

On-grid solar systems are connected to the utility grid, making them an ideal solution for reducing electricity bills and supporting clean energy initiatives. These systems allow users to export excess energy back to the grid, offering significant financial and environmental benefits.

Key Components and Specifications

1. Solar Panels:

• o Same high-efficiency panels as off-grid systems.

2. Grid-Tie Inverters::

• o Converts DC power from panels to AC power for grid compatibility.
• Advanced features:
  • • Anti-islanding protection.
  • • Real-time energy monitoring.

o Capacity: 1kW to 500kW.

3. Net-Metering Compatibility:

• o Supports net metering to track energy export and import.

4. Monitoring Systems:

• o Cloud-based monitoring systems for performance tracking and fault diagnosis.
